CONSTRUCTION: Round 4″ fixtures with integral LEDs. Isolated external driver factory installed inside junction box. One driver for every fixture required. MOUNTING: Cut hole in ceiling and snap fixture in opening with attached spring clips. Space in ceiling needed for the driver to fit through the hole – 2″. • Default Driver Input Voltage: 120V AC (Dimmable) • Optional Driver Input Voltage: 277V-347V AC (Not Dimmable) • Power factor: > 0.95 • Energy Used: 9W • Halogen equivalent: 50W • Beam Angle: 120° • Light colour options: Warm White 3000K and Neutral White 4100K • Light output: Soft White 550 lm, Neutral White 600 lm • CRI: 84 for the 3000K and 82 for the 4100K • Ambient Operating Temperature: -40°F (-40°C) to +104°F (+40°C) • Compliance: c ULus Listed, certified to CSA STD. 250.0 • Rated: Type IC (Direct Contact with Insulation), Energy Star, Air-Tight DIMENSIONS: • ID 4 1/8″; OD 4 3/4″; Thickness 1/2″ • Cut out: 4 1/8″ to 4 1/4″ • Junction Box Dimensions (with driver inside): 3 5/16″ x 3 5/16″ x 1 1/8″ Suitable for damp locations and soffit installations.

EASY INSTALL SLIM LED: an ultra-thin profile, integrated LED and a slim junction box will not interfere with your joists or ductwork. Effortless push and click. The light fixtures are available as incandescent flush lights, fluorescent recessed lights and energy saving LED recessed lights, all are great for the kitchen, hallways, bedrooms and approved.

CONNECTING THE DRIVER: Open the cover of the junction box. Push and remove one of the half-inch knockouts on the side plate. Install standard L16 cable connector. Use double connector for daisy chaining multiple drivers. Furuno gaas fet front end manual. Insert line voltage feed into the cable connector and splice same colour wires using wire nuts.

Close the cover. Connect the driver to the light fixture – the arrows on the male and female parts of the connector between the driver and the fixture should match.

Tighten the connector by hand. Do not attach the junction box to anything so you can pull it through the ceiling opening in case you need to service the driver in future. OPTIONS FOR LOCATING DRIVER: Fixture comes connected to the driver by 12″ long low voltage cable with waterproof connector in the middle. Depending on where you want the driver to be you have 2 options: • Locate next to the fixture – run line voltage wiring to first junction box and “daisy chain” to the junction boxes of the other fixtures. • Or install all drivers at one location and use low voltage extension cables to the fixtures.

Use only extensions provided by the manufacturer. Available jumper cables are 6 feet (1.8m) and 20 feet (6m). Cables are linkable. Maximum run should not exceed 40 feet (12m).

DIMMING: We recommend LED/CFL dimmers that have a low range adjustment dial. After all fixtures are connected to the dimmer adjust the dial to the lowest position before the lights start to flicker of shut down. This setting depends on the local voltage and number of fixtures per dimmer. WARNING: DO NOT USE ANY OTHER DRIVERS EXCEPT THE LOTUS DRIVERS THAT ARE INCLUDED WITH THE FIXTURE. DO NOT CONNECT MULTIPLE FIXTURES TO ONE DRIVER. DO NOT OPEN THE LIGHT FIXTURE AND THE SIDE PLATES OF THE DRIVER – NO SERVICEABLE PARTS INSIDE.
